Models:
CS1 – 59'' x 72": sink base to center column (no equipment end)
CS2 – 103.5'' x 72'': full central with 42” equipment base
CS3 – 109.5'' x 72'': full central with 48” equipment base
CS4 – 59'' x 90'': sink base to center column (no equipment end)
CS5 – 103.5'' x 90'': full central with 42” equipment base
CS6 – 109.5'' x 90'': full central with 48” equipment base
CS7 – 59'' x 95'': sink base to center column and extension (no equipment end)
CS8 – 103.5'' x 95'': full central with 42” equipment base and extension
CS9 – 109.5'' x 95": full central with 48” equipment base and extension
Structure:
Powder-coated, 18-gauge cold-rolled steel; multi-piece shell and frame design; riveted
Door and drawer front/back:
12-mm seamless polymer-covered front; melamine back (Frost in color)
Door and drawer core:
45-lb LEED® IEQ-compliant MDF board,
¾"-thick (all composite wood material to meet CARB P2 emission standard of CARB regulation 91320.4)
Hinges:
Manufacturer's standard Blum® concealed,
self-closing, 110°-opening, nickel-plated metal, clip-on mount, three adjustment points
Soft-close, full-extension, ball-bearing glides
Soft-close, concealed steel hinges
Pulls:
128-mm pull offering (Serenity, Transcend and Pinnacle styles); integrated front-pull design (Cove style); recessed clear snap-on handle with interchangeable color strips (Renew style)
Deep-drawer construction:
One-piece, molded polystyrene drawer bodies with rounded corners (Frost in color)
Slide:
Manufacturer's standard Accuride® Aero (100-lb capacity) ball-bearing slides; Accuride® model 3832 (100-lb capacity) for pullout writing surfaces and waste cans
Security:
Keyed and key-less lock options
Standard panel color options:
12 woodgrains
5 solids
4 metallics
Panel style options:
Cove
Serenity
Renew
Transcend
Pinnacle
Handle style options:
Arc
Bent
Bent Antimicrobial
Edge
Flare
Standard countertop options:
11 Formica® and Wilsonart® laminate colors
15 Corian® solid-surface colors
13 Zodiaq® and Viatera® quartz colors
Sink options:
Laminate Countertop – drop-in sink, touch proximity faucet and soap dispenser
Solid-Surface Countertop – undermount stainless-steel sink, touch proximity faucet and soap dispenser
Quartz Countertop – undermount
stainless-steel sink, touch proximity faucet and soap dispenser
